Ultra Power

Ultra Power UP7 AC 200W / DC 400W Dual Port Multi-Chemistry Smart Charger

In stock
SKU: UPTUP7
$184.60

Product details

  • Vendor Ultra Power
  • SKU UPTUP7
Description

UP7 AC 200W / DC 400W Dual Port Multi-Chemistry Smart Charger.

The UP7 400W 10A Smart Dual Channel AC/DC Charger from Ultra Power is a dual port charger capable of up to 200W of total power on the built in AC Power Supply, or 400W of total power when powered by an external DC power source (sold separately). Each charge channel supplies up to a maximum of 10 Amps to charge your batteries quickly, and the integrated balance port allows you to charge them safely. The dual charge channels are independent, and allow for load biasing for the best possible performance. The UP7 is compatible with Ultra Power's UP-D200 External Battery Discharger (sold separately) for hobbyists who need to cycle or rapidly discharge an unused battery pack. The large 2.4" IPS color screen provides loads of information about your battery's status at a glance. This charger is built for the RC and hobby enthusiast, and has many advanced features.

Specifications:

  • Input Voltage: AC 100 - 240V, DC 9.0 - 32.0V
  • Output Voltage: 0.1 - 30.0V
  • Charging Current: 0.1 - 10.0A x2
  • Discharge Current: CH1: 0.1 - 2.0A (0.1 - 15.0A External Charge Mode); CH2: 0.1 - 2.0A
  • Charge Power: DC Input: 2 x 200W; AC Input: MAX 200W (CH1+CH2=200W); Supports power distribution
  • Discharge Power: CH1: 6W (200W External Discharge Mode); CH2: 6W
  • Balance Current: MAX 1000mA/cell via integrated balance port
  • Support Battery Types: LiPo / LiHV / LiFe / Li-Ion (1-6S); NiMH / NiCd (1-16S); Lead Acid (2-24V)
  • LCD Screen Type: 2.4" 320x240 IPS LCD
  • Dimensions: 100x99x64mm
  • Weight: 450g

    •
